ABC Powder Fire Extinguishers

MODEL SA-01-ABC SA-02-ABC SA-04-ABC SA-06-ABC SA-09-ABC
Capacity 1kg 2kg 4kg 6kg 9kg
Confirming IS Code 15683 15683 15683 15683 15683
Type of Extinguishers
Stored Pressure
Type of Extinguisher Media
Mono Ammonium Phosphate Base Dry Powder Confirming to IS:14609
Expellant
Pressurized with Nitrogen (N2) Gas
Diameter (Approx) 86 ± 10 mm 108 ± 10 mm 140 ± 10 mm 150 ± 10 mm 175 ± 10 mm
Height (Approx) 300 mm 350 mm 490 mm 500 mm 550 mm
Filled Weight (Approx) 2.0 kg 3.4 kg 6.4 kg 9.4 kg 12.5 kg
Empty Weight (Approx) 1.0 kg 1.4 kg 2.4 kg 3.4 kg 3.5 kg
Average Discharge Time 9.0 sec. 11.0 sec. 14.0 sec. 17.0 sec. 25.0 sec.
Operating Temperature
-20°C to 55°C
Working Pressure at 20°C
15.5bar
Maximum Service Pressure
17.5bar
Hydraulic Test Pressure
35.0bar
Fire Rating 1A 21B 1A 21B 2A 55B 3A 89B 3A 144B
Approvals BIS & CE BIS & CE BIS & CE BIS & CE BIS & CE
